FinCube - Privacy-Preserving B2B Financial Infrastructure for Enterprise Platforms

Brain Station 23 PLC

Made by Web3 Team - Brain Station 23 PLC

FinCube is an enterprise-grade, privacy-preserving financial infrastructure enabling secure B2B transfers using Zero-Knowledge Proofs (ZKP) and blockchain technology. Built on Circle's USDC stablecoin, FinCube provides instant, low-cost, transparent cross-border payments with enterprise-grade privacy and security.

The platform combines on-chain governance (FinCubeDAO), privacy-preserving transfers, AI-powered fraud detection, and a modern web interface to deliver next-generation B2B payment infrastructure.

🌟 Key Features

  • 🔐 Privacy-Preserving Transfers: Zero-knowledge proofs enable membership verification without revealing sensitive information
  • 💰 USDC Stablecoin Integration: Built on Circle's USDC, the world's leading digital dollar with over $40B in circulation and the highest transaction volume among stablecoins
  • 🌍 Global Payment Infrastructure: Leverages stablecoins as the emerging standard for worldwide payments and cross-border transfers
  • 🔌 EVM Compatibility: Plug-and-play support for any EVM-compatible blockchain (Ethereum, Polygon, Arbitrum, Celo, etc.)
  • 📈 Scalable Architecture: Batch-based polynomial system supports unlimited users
  • 📊 Event-Driven Design: RabbitMQ integration for audit trails and analytics
  • 🛡️ Cryptographic Security: BN254 curve, Poseidon2 hashing, Honk proof system
  • 🤖 AI-Powered Fraud Detection: Real-time fraud analysis using K-NN and LLM-enhanced detection
  • 🎨 Modern Web Interface: React-based frontend with real-time transaction tracking
  • ⚡ On-Chain Verification: All cross-organization transfers verified on blockchain

📋 Table of Contents

  1. System Architecture
  2. Core Components
  3. Transfer Flow
  4. Zero-Knowledge Proof System
  5. Smart Contracts
  6. Fraud Detection
  7. Frontend Application
  8. Getting Started
  9. API Documentation
  10. Deployment
  11. Security & Privacy
  12. Documentation
  13. What's Implemented
  14. Future Enhancements
  15. Contributing
  16. Support & Resources
  17. License

🏗️ System Architecture

High-Level Overview

┌─────────────────────────────────────────────────────────────────────┐
│                         Client Applications                          │
│                    (Web, Mobile, API Consumers)                      │
└────────────────────────────┬────────────────────────────────────────┘
                             │
                             │ HTTPS/REST
                             ▼
┌─────────────────────────────────────────────────────────────────────┐
│                    Express.js API Gateway (Port 7000)                │
│  ┌──────────────┐  ┌──────────────┐  ┌──────────────┐             │
│  │   Transfer   │  │     Proof    │  │    Query     │             │
│  │  Controller  │  │  Controller  │  │  Controller  │             │
│  └──────────────┘  └──────────────┘  └──────────────┘             │
└────────────────────────────┬────────────────────────────────────────┘
                             │
        ┌────────────────────┼────────────────────┐
        │                    │                    │
        ▼                    ▼                    ▼
┌──────────────┐    ┌──────────────┐    ┌──────────────┐
│   MongoDB    │    │  EVM Chain   │    │   RabbitMQ   │
│              │    │  (Any EVM)   │    │              │
│ - Users      │    │              │    │ - Tx Events  │
│ - Orgs       │    │ - FinCube    │    │ - Audit      │
│ - Batches    │    │ - Verifier   │    │ - Analytics  │
│ - Events     │    │ - ERC20      │    │              │
└──────────────┘    └──────────────┘    └──────────────┘
        │                    │                    │
        └────────────────────┴────────────────────┘
                             │
                             ▼
                    ┌──────────────┐
                    │  ZKP System  │
                    │              │
                    │ - Noir       │
                    │ - Barretenberg│
                    │ - Poseidon2  │
                    └──────────────┘

Technology Stack

Backend:

  • Node.js 18+ with Express.js
  • MongoDB + Mongoose ODM
  • RabbitMQ (Event streaming)
  • Ethers.js (EVM interaction)

Frontend:

  • React 18.2.0 with TypeScript
  • Vite 7.1.2 (Build tool)
  • Zustand 5.0.8 (State management)
  • GraphQL integration

Blockchain:

  • Solidity smart contracts (FinCube, HonkVerifier)
  • Any EVM-compatible RPC provider
  • Circle's USDC stablecoin (primary integration)
  • Support for additional ERC20 tokens

Cryptography:

  • Noir (ZKP circuit language)
  • Barretenberg (Proving backend)
  • Poseidon2 (Hash function)
  • BN254 elliptic curve

AI/ML:

  • FastAPI (Python backend)
  • OpenSearch (Vector database)
  • Google Gemini (LLM analysis)
  • K-NN fraud detection

🧩 Core Components

1. B2B Membership Service (backend/b2b-membership/)

The main application service that orchestrates transfers, manages users, and coordinates with blockchain.

Key Features:

  • Transfer execution (same-org and cross-org)
  • User and organization management
  • Proof generation coordination
  • Blockchain transaction execution
  • Event publishing to RabbitMQ

2. ZKP Base System (backend/base/)

The cryptographic foundation providing zero-knowledge proof capabilities.

Key Features:

  • Noir circuit definition
  • Polynomial generation and evaluation
  • Secret derivation (SHA-256 + BN254 field reduction)
  • Proof generation (Barretenberg)
  • Max polynomial degree: 128 (supports 128 users per batch)

3. Smart Contracts (web3/contracts/)

Solidity contracts deployed on EVM-compatible chains.

Contracts:

  • FinCubeDAO: DAO contract for governance and membership management
  • FinCube: Main transfer contract with ZKP verification
  • HonkVerifier: On-chain proof verification

4. Fraud Detection Service (sc_fraud_detection/)

AI-powered fraud detection using machine learning and LLM analysis.

Features:

  • Real-time address analysis
  • 44-dimensional feature extraction
  • K-NN similarity search
  • LLM-enhanced decision making

5. Frontend Application (frontend/)

React-based web application for user interaction.

Features:

  • User authentication and profile management
  • Secure token transfers
  • Transaction history with fraud detection
  • Real-time balance tracking

6. Web3-Kit: Audit Trail Service

A mission-critical, plug-and-play microservice that provides enterprise-grade blockchain activity tracking and audit capabilities with guaranteed performance SLAs.

Purpose:

  • Track and index blockchain transactions related to business operations in an enterprise-grade manner
  • Provide complete audit trails for regulatory compliance (AML/CTF, KYC)
  • Enable real-time monitoring of DAO operations and FinCube transfers with low latency
  • Scalable to any blockchain use case with 99.5% uptime guarantee

Key Features:

  • Real-Time Event Tracking: Captures on-chain events with
  • Fault-Tolerant Recovery: Automatic reconciliation via The Graph every 30 seconds
  • Enterprise-Level Indexing: Maintains off-chain database with only business-relevant transactions
  • Event-Driven Architecture: Asynchronous Pub/Sub pattern for non-blocking user experience
  • At-Least-Once Delivery: RabbitMQ guarantees no event loss with retry policy
  • Dual-Source Monitoring: Alchemy RPC (real-time) + TheGraph (backfill) for 100% coverage
  • Background Processing: Scheduled cron jobs (*/30 * * * * *) for missed transactions
  • Database Migrations: TypeORM-based PostgreSQL schema management

Technology Stack:

  • NestJS: Modern Node.js framework for scalable server-side applications
  • PostgreSQL + TypeORM: Enterprise database with migration support (Port 5434)
  • Alchemy RPC: Primary blockchain data provider for real-time events
  • TheGraph Protocol: Secondary data source for redundancy and backfill
  • RabbitMQ: Message queue with at-least-once delivery guarantee
  • Kong Gateway: API gateway with RabbitMQ publisher plugin

Current Implementations:

  • DAO governance activity tracking
  • FinCube transfer monitoring
  • Smart contract event detection
  • Transaction receipt processing
  • Cross-chain event aggregation

🔗 Web3-Kit Integration: Seamless Audit Trail

Architecture Overview

FinCube's backend seamlessly integrates with the Audit Trail Service to provide comprehensive blockchain activity monitoring and regulatory compliance. This integration ensures that every transaction, governance action, and smart contract interaction is automatically tracked and auditable.

┌─────────────────────────────────────────────────────────────────────┐
│                         Frontend Application                         │
└────────────────────────────┬────────────────────────────────────────┘
                             │
                             │ HTTPS/REST
                             ▼
┌─────────────────────────────────────────────────────────────────────┐
│                      Kong API Gateway                                │
│                   (RabbitMQ Publisher Plugin)                        │
└────────────────────────────┬────────────────────────────────────────┘
                             │
        ┌────────────────────┼────────────────────┐
        │                    │                    │
        ▼                    ▼                    ▼
┌──────────────┐    ┌──────────────┐    ┌──────────────┐
│ B2B Backend  │    │ Audit Trail  │    │   RabbitMQ   │
│ (Port 7000)  │    │   Service    │    │   Broker     │
│              │    │ (NestJS)     │    │              │
│ - Transfers  │◄──►│              │◄──►│ - Events     │
│ - Proofs     │    │ - Tracking   │    │ - Queues     │
│ - Queries    │    │ - Validation │    │ - Exchanges  │
└──────────────┘    └──────────────┘    └──────────────┘
        │                    │                    │
        └────────────────────┼────────────────────┘
                             │
                             ▼
                    ┌──────────────┐
                    │  Blockchain  │
                    │              │
                    │ - Alchemy    │
                    │ - TheGraph   │
                    │ - Events     │
                    └──────────────┘

Integration Components

1. Kong Gateway Integration

Purpose: Captures on-chain transaction data directly from frontend requests

How It Works:

  • Kong's rabbitmq-publisher plugin automatically publishes transaction events
  • Every API call that results in blockchain interaction is tracked
  • Events are published to RabbitMQ exchanges for processing
  • No additional code required in frontend or backend

Integration Characteristics:

  • Zero-configuration event capture through Kong Gateway's RabbitMQ publisher plugin
  • Complete transaction coverage with at-least-once delivery guarantee via RabbitMQ
  • Reliable delivery mechanism where Kong ensures event publishing even during temporary service unavailability
  • Asynchronous processing model providing non-blocking user experience with immediate transaction hash response

Why Event-Driven Architecture?

Traditional synchronous approaches would force users to wait for blockchain confirmation (several seconds to minutes), creating poor user experience. FinCube's event-driven architecture solves this:

The Problem: Blockchain transactions require confirmation across multiple blocks, which can take significant time depending on network congestion and gas fees.

The Solution: Asynchronous Pub/Sub flow that provides instant user feedback while processing confirmations in the background.

Flow:

  1. User Action: User initiates blockchain transaction
  2. Immediate Response: Frontend receives transaction hash instantly - no waiting
  3. Background Processing:
    • Audit Trail listens to RPC events in real-time
    • Missed events are backfilled via The Graph (every 30 seconds)
  4. Event Publishing: When transaction is finalized on-chain:
    • Audit Trail publishes acknowledgement to RabbitMQ
    • All microservices update their off-chain databases asynchronously

Result: Users get instant feedback while the system maintains eventual consistency in the background, providing both excellent UX and data integrity.

2. Dual-Source Event Detection

Challenge: Blockchain networks can be unreliable, and single data sources may miss events

Solution: Fault-tolerant monitoring using both Alchemy and TheGraph

Architecture:

Blockchain Events
       │
       ├─────────────────────────────────────┐
       │                                     │
       ▼                                     ▼
┌─────────────┐                    ┌─────────────┐
│   Alchemy   │                    │  TheGraph   │
│   Listener  │                    │   Listener  │
│             │                    │             │
│ - Real-time │                    │ - Indexed   │
│ - Direct    │                    │ - Reliable  │
│ - Fast      │                    │ - Queryable │
└─────────────┘                    └─────────────┘
       │                                     │
       └─────────────┬───────────────────────┘
                     │
                     ▼
            ┌─────────────────┐
            │ Event Validator │
            │                 │
            │ - Deduplication │
            │ - Verification  │
            │ - Enrichment    │
            └─────────────────┘
                     │
                     ▼
              ┌─────────────┐
              │  Database   │
              │   Storage   │
              └─────────────┘

Automatic Failover:

  • If Alchemy is down → TheGraph continues monitoring
  • If TheGraph is delayed → Alchemy provides real-time data
  • Cross-validation ensures data accuracy
  • No events are missed due to service outages

3. Event Processing Pipeline

Step 1: Event Capture

Blockchain Transaction
       │
       ▼
┌─────────────────┐
│ Kong Gateway    │
│ RabbitMQ Plugin │
└─────────────────┘
       │
       ▼
┌─────────────────┐
│ RabbitMQ        │
│ Exchange        │
└─────────────────┘

Step 2: Event Enrichment

Raw Event Data
       │
       ▼
┌─────────────────┐
│ Audit Service   │
│ - Add metadata  │
│ - Validate data │
│ - Enrich context│
└─────────────────┘

Step 3: Event Distribution

Enriched Event
       │
       ├─────────────────────────────────────┐
       │                                     │
       ▼                                     ▼
┌─────────────┐                    ┌─────────────┐
│ Audit Trail │                    │ Analytics   │
│ Database    │                    │ Service     │
└─────────────┘                    └─────────────┘
       │                                     │
       ▼                                     ▼
┌─────────────┐                    ┌─────────────┐
│ Compliance  │                    │ Monitoring  │
│ Reporting   │                    │ Alerts      │
└─────────────┘                    └─────────────┘

Tracked Activities

FinCube Transfers

  • Transfer initiation and completion
  • ZKP proof generation and verification
  • Nullifier usage and validation
  • Gas usage and transaction costs
  • Cross-organization transfer details
  • Same-organization optimizations

DAO Operations

  • Member registration and approval
  • Proposal creation and voting
  • Governance parameter changes
  • Fee structure updates
  • Token approval decisions

Smart Contract Events

  • Contract deployments and upgrades
  • Function calls and state changes
  • Event emissions and logs
  • Error conditions and reverts

API Integration

Audit Trail Service Endpoint: /audit-trail-service

Key API Routes:

GET  /audit-trail-service/transactions/:txHash
GET  /audit-trail-service/address/:address/history
GET  /audit-trail-service/dao/proposals
GET  /audit-trail-service/compliance/report
POST /audit-trail-service/events/validate

Event Contract:

The Audit Trail Service publishes standardized events following this schema:

{
  "web3Status": 1,
  "message": "Transaction updated successfully.",
  "data": {
    "proposalId": 786,
    "proposalType": "External",
    "proposedWallet": "0xWaLlEt",
    "__typename": "EventName"
  },
  "blockNumber": 123456,
  "transactionHash": "0xtrx_hash"
}

Event Naming Convention:

  • Format: <network>.<contract_name>.<event_name>
  • Style: lowercase, snake_case
  • Example: sepolia.fincube.transfer_completed

Backend Integration Example:

// Automatic event publishing after transfer
const publishTransferEvent = async (transferData) => {
  const event = {
    type: 'FINCUBE_TRANSFER',
    timestamp: new Date().toISOString(),
    data: {
      transactionHash: transferData.txHash,
      from: transferData.sender,
      to: transferData.receiver,
      amount: transferData.amount,
      nullifier: transferData.nullifier,
      proofVerified: true
    }
  };

  // Published automatically via Kong Gateway
  // No manual RabbitMQ calls needed
  // Guaranteed delivery with at-least-once semantics
};

RabbitMQ Exchange Configuration:

Parameter Value
Exchange Type fanout
Exchange Name exchange.web3_event_hub.fanout
Delivery Guarantee At-least-once
Queue Ownership Each service maintains its own dedicated queue
Idempotency Required for duplicate event handling

Compliance Benefits

Regulatory Reporting

  • AML/CTF Compliance: Complete transaction trails for anti-money laundering
  • KYC Verification: Audit trail of member verification processes
  • Tax Reporting: Detailed transaction history for tax compliance
  • Regulatory Audits: Ready-to-submit audit reports

Real-Time Monitoring

  • Fraud Detection: Immediate alerts for suspicious activities
  • Operational Monitoring: System health and performance tracking
  • Compliance Violations: Automatic detection of policy breaches
  • Risk Management: Real-time risk assessment and mitigation

Data Integrity

  • Immutable Records: Blockchain-backed audit trails
  • Cross-Validation: Multiple data sources ensure accuracy
  • Tamper-Proof: Cryptographic verification of all records
  • Complete Coverage: No transaction goes untracked

Scalability Features

Horizontal Scaling

  • Microservice Architecture: Independent scaling of audit components
  • Load Balancing: Distribute event processing across multiple instances
  • Queue Management: RabbitMQ handles high-volume event streams
  • Database Sharding: Partition audit data for performance

Multi-Blockchain Support

  • Chain Agnostic: Works with any EVM-compatible blockchain
  • Unified Interface: Single API for all blockchain networks
  • Cross-Chain Tracking: Monitor activities across multiple chains
  • Network Failover: Automatic switching between blockchain providers

Business Impact

For Organizations:

  • Regulatory compliance meeting all audit and reporting requirements
  • Risk management through real-time monitoring and fraud detection
  • Operational efficiency via automated audit trail generation
  • Cost reduction eliminating manual compliance processes

For Regulators:

  • Complete transparency providing full visibility into all transactions
  • Real-time access with immediate availability of audit data
  • Standardized reporting using consistent audit trail format
  • Fraud prevention through proactive detection of suspicious activities

For Developers:

  • Plug-and-play integration requiring no code changes for audit functionality
  • Comprehensive APIs providing rich set of audit and compliance endpoints
  • Event-driven architecture reacting to blockchain events with ≤3 second latency
  • Scalable architecture handling enterprise-scale transaction volumes
  • SLA-backed service with 99.5% uptime and defined performance guarantees
  • Database migrations using TypeORM-based PostgreSQL schema management

Service Level Agreement (SLA)

The Audit Trail Service operates under a comprehensive SLA to ensure enterprise-grade reliability.

Service Dependencies:

  • Alchemy RPC Nodes: Live blockchain event streaming
  • The Graph Protocol: Querying missed/pending transactions
  • RabbitMQ Broker: Event distribution infrastructure

Note: Service uptime and performance are dependent on third-party providers. The Audit Trail Service includes fault-tolerant mechanisms (retry logic, cron-based reconciliation), but cannot guarantee SLA compliance during third-party outages.

🔄 Transfer Flow

Complete Transfer Sequence

The following diagram illustrates the complete flow from user registration to cross-organization transfer:

sequenceDiagram
    participant User1 as User 1
    participant OrgA as Organization A
    participant DAO as DAO Contract
    participant OrgB as Organization B
    participant User2 as User 2
    participant Blockchain as Blockchain (Event Log)

    User1->>OrgA: Register (email, user details)
    OrgA->>DAO: Request reference number (email_hash, org_reference_key)
    DAO->>DAO: Compute reference_number = keccak256(email_hash, org_reference_key, salt)
    DAO-->>OrgA: Return reference_number
    DAO-->>Blockchain: Emit ReferenceNumberIssued(org_id, reference_number)
    OrgA->>OrgA: Store reference_number and assign to User1

    User2->>OrgB: Register (email, user details)
    OrgB->>DAO: Request reference number (email_hash, org_reference_key)
    DAO->>DAO: Compute reference_number = keccak256(email_hash, org_reference_key, salt)
    DAO-->>OrgB: Return reference_number
    DAO-->>Blockchain: Emit ReferenceNumberIssued(org_id, reference_number)
    OrgB->>OrgB: Store reference_number and assign to User2

    User1->>OrgA: Send(receiver_reference_number, amount)
    OrgA->>OrgA: Lookup receiver org (OrgB) using DAO event index
    OrgA->>OrgB: Send(receiver_reference_number, ZK proof u1 ∈ OrgA)
    OrgB->>OrgB: Verify ZK proof
    OrgB->>User2: Lookup user by receiver_reference_number
    OrgB->>OrgA: Return ZK proof u2 ∈ OrgB
    OrgA->>OrgA: Verify proof
    OrgA->>OrgB: Transfer stablecoin (ERC20)
    OrgA->>User1: Update balance (debit)
    OrgB->>User2: Update balance (credit)
    OrgB->>Blockchain: Emit TransactionRecorded(sender_reference, receiver_reference, amount, invoice)
Loading

Transfer Execution Flow

The system executes privacy-preserving transfers with the following steps:

1. [STEP 1/7] Validate Input
2. [STEP 2/7] Retrieve User Data
3. [STEP 3/7] Generate ZKP Proof (receiver membership)
4. [STEP 4/7] Generate Nullifier (unique tx ID)
5. [STEP 5/7] Create Memo (transfer metadata)
6. [STEP 6/7] Execute Blockchain Transfer
7. [STEP 7/7] Publish to RabbitMQ
8. Update Database Balances

Key Characteristics:

  • 🔐 Cryptographically secure with ZKP
  • ⛓️ On-chain verification via smart contracts
  • 📝 Complete audit trail through RabbitMQ
  • 🔒 Privacy-preserving membership verification
  • 💸 Gas-efficient proof verification
  • 🌐 Works on any EVM-compatible blockchain

🔐 Zero-Knowledge Proof System

Core Concept

Polynomial Membership Proof:

  1. Organization creates a polynomial where member secrets are roots
  2. User proves they know a secret that evaluates to zero on the polynomial
  3. Proof reveals nothing about the user's identity or other members

Cryptographic Components

Secret Generation

User Secret = SHA-256(zkp_key || org_salt) mod BN254_FIELD_PRIME

Polynomial Structure

P(x) = c₀ + c₁x + c₂x² + ... + c₁₂₈x¹²⁸

Properties:

  • Maximum degree: 128 (supports 128 members per batch)
  • Coefficients: BigInt strings stored in MongoDB
  • Evaluation: P(secret) = 0 for valid members

Nullifier Generation

Nullifier = Poseidon2(secret, verifier_key)

Scalability: Batch System

Challenge: Polynomial degree limited to 128

Solution: Multiple independent batches

Organization
├── Batch 1 (Polynomial P₁) → Users 1-128
├── Batch 2 (Polynomial P₂) → Users 129-256
├── Batch 3 (Polynomial P₃) → Users 257-384
└── Batch N (Polynomial Pₙ) → Users ...

💰 USDC Stablecoin Integration

FinCube is built on Circle's USD Coin (USDC), the world's leading digital dollar:

  • $40+ Billion in circulation globally
  • 1:1 USD backing with monthly attestations by Grant Thornton LLP
  • Available on 15+ blockchains (Ethereum, Polygon, Arbitrum, etc.)
  • Regulated by U.S. state money transmitter licenses
  • Institutional grade - used by major financial institutions and Fortune 500 companies

For detailed business benefits and value propositions, see PROJECT_DESCRIPTION.md.

📜 Smart Contracts

FinCubeDAO Contract

Purpose: Governance and membership management

Key Features:

  • Upgradeable via UUPS (UUPSUpgradeable, OwnableUpgradeable, ReentrancyGuardUpgradeable)
  • Members: registerMember, on execution of a NewMemberProposal the DAO approves members
  • Governance parameters: setVotingDelay(seconds), setVotingPeriod(seconds)
  • Proposals:
    • newMemberApprovalProposal(address, description)
    • propose(address[] targets, uint256[] values, bytes[] calldatas, string description)
  • Voting: castVote(proposalId, support) with a simple majority threshold ceil(memberCount/2)
  • Execution: executeProposal(proposalId) after voteEnd and with sufficient yesvotes
  • Reference Number Generation: generateReferenceNumber(emailHash, orgReferenceKey) - Creates unique user identifiers

FinCube Contract

Purpose: Main transfer contract with ZKP verification

Key Function:

function safeTransfer(
    address to,
    uint256 amount,
    string calldata memo,
    bytes32 nullifier,
    bytes32 sender_reference_number,
    bytes32 receiver_reference_number,
    bytes calldata receiver_proof,
    bytes32[] calldata receiver_publicInputs
) external

Features:

  • ✅ Verifies receiver's ZKP proof via HonkVerifier
  • ✅ Checks nullifier uniqueness (prevents double-spending)
  • ✅ Transfers Circle's USDC stablecoin (or any approved ERC20 token)
  • ✅ Emits transfer events for audit trail
  • ✅ Supports memo for transaction metadata (ISO:20022 standard)
  • ✅ Multi-chain support: Works with USDC on Ethereum, Polygon, Arbitrum, and more
  • Upgradeable (UUPS) with upgrades authorized only by the DAO

HonkVerifier Contract

Purpose: On-chain ZKP proof verification

Key Function:

function verify(
    bytes calldata proof,
    bytes32[] calldata publicInputs
) external view returns (bool)

🤖 Fraud Detection

AI-Powered Analysis

The fraud detection service uses advanced machine learning techniques:

Feature Extraction: 44-dimensional vectors including:

  • Transaction metrics (counts, values, timing)
  • Address patterns (unique addresses, contract interactions)
  • ERC20 token behavior
  • Balance and volume ratios

K-NN Analysis:

  • HNSW algorithm for similarity search
  • Weighted fraud probability calculation
  • Confidence scoring based on neighbor agreement

LLM Enhancement:

  • Google Gemini for pattern analysis
  • Edge case detection
  • Reasoning generation

Fraud Detection Flow

sequenceDiagram
    participant User as User/Client
    participant API as FastAPI API
    participant FE as Feature Extractor
    participant OS as OpenSearch (Vector DB)
    participant KNN as K-NN Service
    participant RAG as RAG Service (Gemini)

    User->>API: POST /score (transfer_history)
    API->>FE: Extract features from transfer history
    FE->>FE: Calculate 44-dimensional vector
    FE-->>API: Return normalized feature vector

    API->>OS: K-NN search (vector, k=10)
    OS->>OS: HNSW similarity search (L2 distance)
    OS-->>API: Return 10 nearest neighbors

    API->>KNN: Analyze neighbors
    KNN->>KNN: Calculate weighted fraud probability
    KNN-->>API: Return K-NN analysis

    API->>RAG: Request RAG analysis
    RAG->>RAG: Node 1: Analyze K-NN results (Gemini)
    RAG->>RAG: Node 2: Detect edge cases
    RAG->>RAG: Node 3: Final decision (Gemini)
    RAG-->>API: Return final decision + reasoning

    API-->>User: Return JSON response
Loading

🎨 Frontend Application

Features

  • User Authentication: Email/password authentication with JWT tokens
  • Token Transfers: Same-org and cross-org transfers with real-time balance updates
  • Transaction History: GraphQL integration with The Graph subgraph
  • Fraud Detection: Real-time analysis with visual risk indicators
  • User Profile: Account information, balance display, reference number management

Technology Stack

  • React 18.2.0 with TypeScript
  • Vite 7.1.2 (Build tool)
  • Zustand 5.0.8 (State management)
  • Ethers.js 5.7.2 (Blockchain interaction)
  • React Router DOM 6.22.3

Quick Start

cd frontend
yarn install
cp .env.example .env
# Edit .env with your configuration
yarn dev

🚀 Getting Started

Prerequisites

  • Node.js 18+
  • MongoDB
  • RabbitMQ
  • Python 3.8+ (for fraud detection)
  • Yarn package manager
  • EVM-compatible RPC endpoint (Alchemy, Infura, etc.)

Quick Setup

  1. Clone the repository:

    git clone <repository-url>
cd transferPoC

  2. Backend Setup:

    cd backend/b2b-membership
npm install
cp .env.example .env
# Edit .env with your configuration
docker-compose up -d  # Start MongoDB and RabbitMQ
npm start

  3. Frontend Setup:

    cd frontend
yarn install
cp .env.example .env
# Edit .env with your configuration
yarn dev

  4. Fraud Detection Setup:

    cd sc_fraud_detection
pip install -r requirements.txt
cp .env.example .env
# Edit .env with your configuration
python main.py

Environment Configuration

Backend (.env):

# RPC Provider (Any EVM-compatible endpoint)
ALCHEMY_URL=https://your-network-rpc-endpoint
CHAIN_ID=1  # Auto-detected if not specified

# Smart Contracts
HONK_VERIFIER_CONTRACT_ADDRESS=0x...
FINCUBE_CONTRACT_ADDRESS=0x...

# USDC Token Address (varies by network)
# Ethereum Mainnet: 0xA0b86991c6218b36c1d19D4a2e9Eb0cE3606eB48
# Polygon: 0x2791Bca1f2de4661ED88A30C99A7a9449Aa84174
# Arbitrum: 0xFF970A61A04b1cA14834A43f5dE4533eBDDB5CC8
USDC_TOKEN_ADDRESS=0x...

# Wallet
WALLET_PRIVATE_KEY=your_private_key

# MongoDB
MONGODB_URI=mongodb://localhost:27017/b2b-membership

# RabbitMQ
RABBITMQ_HOST=localhost
RABBITMQ_PORT=5672
RABBITMQ_USERNAME=guest
RABBITMQ_PASSWORD=guest

USDC Contract Addresses by Network:

  • Ethereum: 0xA0b86991c6218b36c1d19D4a2e9Eb0cE3606eB48
  • Polygon: 0x2791Bca1f2de4661ED88A30C99A7a9449Aa84174
  • Arbitrum: 0xFF970A61A04b1cA14834A43f5dE4533eBDDB5CC8
  • Optimism: 0x7F5c764cBc14f9669B88837ca1490cCa17c31607
  • Avalanche C-Chain: 0xB97EF9Ef8734C71904D8002F8b6Bc66Dd9c48a6E
  • Base: 0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913

For complete list, visit: Circle's USDC Documentation

📚 API Documentation

Transfer API

POST /api/transfer

{
  "receiver_reference_number": "0x1234...5678_uuid",
  "amount": 100,
  "sender_user_id": 2001
}

Query API

GET /api/query/user/:user_id

  • Retrieve user with populated batch and organization

GET /api/query/organization/:org_id

  • Retrieve organization with all associated users

Proof API

POST /api/proof/generate

  • Generate ZKP proof for membership verification

POST /api/proof/verify

  • Verify proof against on-chain contract

Health Check

GET /health

{
  "status": "ok",
  "service": "zkp-proof-controller",
  "database": "connected",
  "rabbitmq": {
    "consumer": "connected",
    "publisher": "connected"
  }
}

For complete API documentation, see:

🚀 Deployment

EVM Chain Deployment

FinCube is EVM-Agnostic: Deploy to any EVM-compatible blockchain without code modifications.

Supported Networks (Examples):

  • Ethereum (Mainnet, Sepolia, Goerli)
  • Polygon (Mainnet, Mumbai)
  • Arbitrum (One, Goerli)
  • Optimism (Mainnet, Goerli)
  • Avalanche (C-Chain, Fuji)
  • BSC (Mainnet, Testnet)
  • Celo (Mainnet, Alfajores, Sepolia)
  • Base (Mainnet, Goerli)
  • Any EVM-compatible chain

Deploying (UUPS proxies)

You must use proxy deployment for upgradeable contracts. Do not call initialize on implementation contracts.

Remix + ERC1967Proxy

  1. Deploy FinCubeDAO (implementation) — do nothing else with it.
  2. Encode init data for DAO:
    • function: initialize(string _daoURI, string _ownerURI)
    • use Remix’s ABI encoder or web3.eth.abi.encodeFunctionCall.
  3. Deploy ERC1967Proxy with:
    • _logic = DAO implementation
    • _data = encoded init data
    • resulting address is DAO proxy
  4. Deploy FinCube (implementation) — do nothing else with it.
  5. Encode init data for FinCube:
    • function: initialize(address _dao, address _token)
    • _dao = DAO proxy address, _token = initial ERC‑20 (or 0x0)
  6. Deploy ERC1967Proxy for FinCube with its init data — resulting address is FinCube proxy.

Governance parameters

Before proposing/voting, set timing:

DAO.setVotingDelay(0);           // for quick testing
DAO.setVotingPeriod(120);        // e.g., 2 minutes

Voting is allowed when now > voteStart && now < voteEnd, execution requires now ≥ voteEnd and majority yesvotes ≥ proposalThreshold().

Proposals

Propose: update the approved ERC‑20 on FinCube

  • Target: FinCube proxy address
  • Value: 0
  • Calldata: encoded setApprovedERC20(address)

Remix inputs (strict JSON):

{
  "targets": ["0xFinCubeProxy..."],
  "values": [0],
  "calldatas": ["0x314b6256…"],
  "description": "Update approved ERC20"
}

Solidity encoding:

bytes memory data = abi.encodeWithSignature(
    "setApprovedERC20(address)",
    0xYourNewToken...
);

Safer (0.8.12+):

bytes memory data = abi.encodeWithSelector(FinCube.setApprovedERC20.selector, 0xYourNewToken...);
// or: abi.encodeCall(FinCube.setApprovedERC20, (0xYourNewToken...));

ethers v6:

const iface = new ethers.Interface([
  "function setApprovedERC20(address newToken)"
]);
const calldata = iface.encodeFunctionData("setApprovedERC20", [newToken]);

Ensure you pass calldatas as an array of quoted hex strings in Remix.

Voting and execution

  1. Propose as a member.
  2. Vote during the window (now > start && now < end).
  3. After voteEnd, call executeProposal(proposalId). The DAO will:
    • for GeneralProposal: Address.functionCall(target, data)
    • for NewMemberProposal: call approveMember(...) internally

Using safeTransfer

  1. Ensure FinCube.approvedERC20 is set (initially in initialize or via a DAO proposal).
  2. The from account must approve the FinCube proxy on the ERC‑20:
    • approve(FinCubeProxy, amount)
  3. Call safeTransfer(from, to, amount, memo) with Value = 0. Requirements:
    • msg.sender is an approved member
    • from and to are approved members
    • memo is in JSON format following ISO:20022 standard. It will be used for on-ramping and off-ramping.
    • allowance(from, FinCube) ≥ amount and balanceOf(from) ≥ amount

Common reverts & causes

  • Caller/From/To not member — register + approve in DAO first.
  • Insufficient allowance — run approve from the from account.
  • Insufficient balance — top up the from account.
  • Only DAO — attempting to call DAO‑only functions (setApprovedERC20, setDAO).
  • DAO not set / Token not set — check initialize input and/or proposals.

Events

FinCubeDAO

  • MemberRegistered(address newMember, string memberURI)
  • MemberApproved(address member)
  • ProposalAdded(ProposalType, uint256 proposalId, bytes data)
  • ProposalCreated(...)
  • VoteCast(address voter, uint256 proposalId, uint8 support, uint256 weight, string reason)
  • ProposalExecuted(uint256 proposalId)
  • ProposalCanceled(uint256 proposalId)

FinCube

  • DAOUpdated(address newDAO)
  • ApprovedERC20Updated(address newToken)
  • StablecoinTransfer(address from, address to, uint256 amount, string memo)

🛡️ Security & Privacy

Privacy Guarantees

Zero-Knowledge Proofs:

  • ✅ No membership information revealed
  • ✅ Proofs cannot be linked to specific users
  • ✅ Organization structure remains private
  • ✅ Forward secrecy (past proofs valid after member removal)

Cryptographic Security:

  • ✅ BN254 elliptic curve (128-bit security)
  • ✅ Poseidon2 hash function (zk-SNARK optimized)
  • ✅ Honk proof system (efficient verification)
  • ✅ Nullifiers prevent double-spending

Attack Resistance

Verification Caching:

  • Nullifiers prevent redundant verification overhead
  • Cached verifications reduce on-chain costs
  • Unique per (user, verifier) pair

Polynomial Integrity:

  • Hash commitments ensure data authenticity
  • On-chain verification of polynomial hash
  • Prevents polynomial tampering

Replay Attack Prevention:

  • Nullifiers stored on-chain
  • Duplicate nullifiers rejected
  • Transaction uniqueness guaranteed

Security Best Practices

Smart Contract Security:

  • Execution timing: execution requires now ≥ voteEnd. Voting requires now > voteStart && now < voteEnd
  • Threshold stability: current threshold is computed as (memberCount + 1) / 2 at execution time
  • Reentrancy: token transfers use SafeERC20 and nonReentrant guards
  • Proxies: Never call state‑changing functions on implementation contracts; storage lives in the proxies
  • bytesToAddress usage: use the provided toBytes(address) helper when creating NewMemberProposal data

Private Key Management:

  • Never commit private keys to version control
  • Use environment variables for sensitive data
  • Consider hardware wallets for production
  • Implement key rotation policies

API Security:

  • Input validation on all endpoints
  • Rate limiting to prevent abuse
  • HTTPS/TLS for all communications
  • Authentication and authorization

📖 Documentation

Core Documentation

Backend:

Frontend:

Smart Contracts:

Fraud Detection:

Architecture Diagrams

🎯 What's Implemented

✅ Core Features

  • User Registration & Authentication: Complete user management with JWT tokens
  • Reference Number System: On-chain reference number generation via DAO contract
  • USDC Stablecoin Integration: Native support for Circle's USDC across multiple blockchains
  • Privacy-Preserving Transfers: Cross-organization transfers with blockchain verification and ZKP privacy
  • Zero-Knowledge Proofs: Polynomial-based membership verification
  • Smart Contract Integration: FinCube and FinCubeDAO deployed and operational
  • Multi-Chain Support: Works with USDC on Ethereum, Polygon, Arbitrum, and other EVM chains
  • Event-Driven Architecture: RabbitMQ integration for transaction events
  • Fraud Detection: AI-powered fraud analysis with K-NN and LLM
  • Web Interface: React frontend with transaction history and fraud indicators
  • GraphQL Integration: The Graph subgraph for transaction queries

✅ Security Features

  • ZKP Privacy: Membership verification without revealing identity
  • Nullifier System: Prevents double-spending and replay attacks
  • Polynomial Batching: Scalable to unlimited users
  • On-chain Verification: HonkVerifier contract validates proofs
  • Audit Trail: Complete transaction logging via RabbitMQ

✅ Infrastructure

  • EVM Compatibility: Works with any EVM-compatible blockchain
  • MongoDB: User, organization, and batch data storage
  • RabbitMQ: Event streaming and audit logging
  • OpenSearch: Vector database for fraud detection
  • Docker Support: Containerized deployment

🤝 Contributing

We welcome contributions! Please follow these guidelines:

Development Workflow

  1. Fork the repository
  2. Create a feature branch (git checkout -b feature/amazing-feature)
  3. Make your changes
  4. Run tests
  5. Commit your changes (git commit -m 'Add amazing feature')
  6. Push to the branch (git push origin feature/amazing-feature)
  7. Open a Pull Request

Testing

# Backend tests
cd backend/b2b-membership
node run-all-tests.js

# Frontend tests
cd frontend
yarn test

# Fraud detection tests
cd sc_fraud_detection
pytest

📞 Support & Resources

Getting Help

  • Documentation: Review the comprehensive documentation in each component directory
  • Issues: Open an issue on GitHub for bugs or feature requests
  • Discussions: Join community discussions for questions and ideas

External Resources

📄 License

MIT License - see LICENSE file for details

👥 About Brain Station 23 PLC

Brain Station 23 PLC

Brain Station 23 PLC is a leading technology company specializing in enterprise blockchain solutions, Web3 integration, and digital transformation services. Our Web3 Team brings together expertise in:

  • Blockchain Development: Smart contracts, DeFi protocols, and Web3 infrastructure
  • Enterprise Integration: Seamless connection between traditional systems and blockchain
  • Cryptographic Security: Zero-knowledge proofs and advanced privacy solutions
  • Regulatory Compliance: AML/KYC integration and audit-ready systems
  • AI & Machine Learning: Fraud detection and predictive analytics

FinCube represents our commitment to making blockchain technology accessible and practical for enterprise adoption, bridging the gap between Web2 and Web3 with security, compliance, and ease of use.

Contact Brain Station 23

Made by Web3 Team - Brain Station 23 PLC

Built with ❤️ for privacy-preserving B2B financial infrastructure

Last Updated: November 26, 2025
Version: 1.0.0

About

PoC for stablecoin transfer using FinCube

Resources

Readme
Activity
Custom properties

Stars

0 stars

Watchers

0 watching

Forks

0 forks
Report repository

Releases

No releases published

Packages

No packages published

Contributors 6

Languages
